TPMS AT09

Description

• Product Specifications:

  • Network Compatibility: Supports 2G, 3G, and 4G LTE networks.​

  • GPS Module: Utilizes high-precision GPS and GLONASS for accurate location tracking.​

  • Power Supply: Operates on an external power source ranging from +12V to +50V DC at 1.5A.​

  • Internal Battery: Equipped with an 800mAh rechargeable lithium-polymer battery, resistant to high temperatures up to 80°C.​

  • Power Consumption: Normal consumption is 2W, peaking at 12.5W.​

  • Dimensions: Measures 112×80×25mm.​

  • Weight: 150g.​

  • Memory: 16Mb Flash Memory, capable of storing approximately 4,000 data points.​

  • Operating Temperature: Functions between -20°C to 60°C.​

  • Humidity Tolerance: 5% to 95% non-condensing.​

  • Inputs/Outputs:

    • 4 digital inputs.

    • 4 digital outputs.

    • 4 analog inputs.

    • 2 RS232 ports.

    • 1 RS485 port.

    • 2 1-Wire interfaces for temperature sensors.

    • Ports for voice communication: microphone and speaker interfaces.

    • SOS button input.

    • USB port for debugging and configuration.

• Features:

  • Real-time Tracking: Provides accurate, real-time location updates.​

  • Tire Pressure Monitoring System (TPMS): Monitors tire pressure and temperature in real-time, supporting up to 42 sensors.​

  • Wi-Fi Hotspot: Offers internet access to passengers’ devices and supports peripherals like IP cameras and dash cameras.​totemtek.com

  • LoRa and Bluetooth Support: Facilitates better network connections to various IoT devices.​

  • Voice Monitoring: Integrated microphone and speaker for two-way voice communication.​

  • Fuel Level Monitoring: Supports high-accuracy fuel or oil level detection.​

  • Temperature Monitoring: Simultaneously monitors two temperature sensors.​totemtek.com+2LinkedIn+2LinkedIn+2

  • Multiple Peripheral Support: Interfaces for various accessories, including cameras, RFID readers, and more.​

  • Over-the-Air (OTA) Updates: Supports firmware upgrades remotely.​totemtek.com+1Log in or sign up to view+1

  • Data Transmission: Capable of sending data to two servers simultaneously.​

  • Geofencing: Supports geofencing with alerts for entering or exiting predefined areas.​

  • Multiple Alarms: Includes overspeeding, low battery, vibration, and SOS alarms.
